Itilize Road Bridge Bailey Bridge Pou Vann
Dekri teren
Karakteristik teknik
Atribi kle yo
Endistri espesifik atribis
Klas: Q345B-Q460C
Tolerans: ± 1%
Lòt atribi
Estanda: AiSi
Kote ki gen orijin: Jiangsu, Lachin
Tan livrezon: 15-21 jou
Non mak: BAILEY
Nimewo Modèl: Bailey Bridge HD200
Kalite: lou
Aplikasyon: Steel Estrikti Bridge
Peman: L/C, T/T, ESCROW
MOQ: 1 PC
Pò: Shanghai
Detay livrezon: Dapre lòd la
Kapasite Pwovizyon pou: 10000 tòn / tòn pou chak ane
Anbalaj: 40 'estanda resipyan HQ
Anbalaj ak livrezon
Detay anbalaj: 321 style treastle Bailey pon anbalaj: 40 'estanda resipyan HQ
Pò: Shanghai
Kapasite Pwovizyon pou
Kapasite Pwovizyon pou: 10000 moso / moso pou chak ane 321 style treastle Bailey Bridge
Echantiyon yo
Kantite maksimòm lòd: 1 moso
Egzanp pri:$300.00/pyès
Personnalisation
Logo Customized
Min. lòd: 1
Anbalaj Customized
Min. lòd: 1
Personnalisation grafik
Min. lòd: 1
|
ZB200 bastengal près tab limite
|
|||||||||
|
Non
|
fòs entèn
|
fòm estrikti
|
|||||||
|
pa ranfòse modèl
|
modèl ranfòse
|
||||||||
|
SS
|
dS
|
ts
|
QS
|
SSR
|
DOKTÈ
|
TSR
|
QSR
|
||
|
200
|
moman estanda bastengal (kN.m)
|
1034.3
|
2027.2
|
2978.8
|
3930.3
|
2165.4
|
4244.2
|
6236.4
|
8228.6
|
|
200
|
taye taye estanda (kN)
|
222.1
|
435.3
|
639.6
|
843.9
|
222.1
|
435.3
|
639.6
|
843.9
|
|
201
|
segondè koube bastengal moman (kN.m)
|
1593.2
|
3122.8
|
4585.5
|
6054.3
|
3335.8
|
6538.2
|
9607.1
|
12676.1
|
|
202
|
Segondè taye bastengal koube (kN)
|
348
|
696
|
1044
|
1392
|
348
|
696
|
1044
|
1392
|
|
203
|
Fòs taye nan bastengal taye super wo (kN)
|
509.8
|
999.2
|
1468.2
|
1937.2
|
509.8
|
999.2
|
1468.2
|
1937.2
|
|
ZB200 Tablo karakteristik jewometrik pon bastengal (Mwatye pon)
|
||||
|
estrikti
|
karakteristik jewometrik
|
|||
|
karakteristik jewometrik
|
zòn kòd (cm2)
|
Pwopriyete seksyon (cm3)
|
Moman inèsi (cm4)
|
|
|
ss
|
SS
|
25.48
|
5437
|
580174
|
|
ssR
|
50.96
|
10875
|
1160348
|
|
|
dS
|
dS
|
50.96
|
10875
|
1160348
|
|
DRS1
|
76.44
|
16312
|
1740522
|
|
|
DSR2
|
101.92
|
21750
|
2320696
|
|
|
ts
|
ts
|
76.44
|
16312
|
1740522
|
|
TSR2
|
127.4
|
27185
|
2900870
|
|
|
TSR3
|
152.88
|
32625
|
3481044
|
|
|
QS
|
QS
|
101.92
|
21750
|
2320696
|
|
QSR3
|
178.36
|
38059
|
4061218
|
|
|
QSR4
|
203.84
|
43500
|
4641392
|
|
Baj popilè: itilize wout pon Bailey pon pou vann, Lachin, manifaktirè, faktori, wholesale, bon mache
